Slim LED Flood Light

You are here: Home > LED Flood Light > Slim LED Flood Light

Description Product Dimension User Manual Application Cases

Product Features:

Name: 150W Slim Led Flood Light
Brand: Fanguang Lighting
SKU: FG150W12
Availability: InStock
Rating: 5 (1 reviews)

1.Integrated reflector and entire aluminum lamp cooling structure;
2.Ultra-thin sleek design, fashionable and classical
3.Innovative G-type buckle technology, guard against glass falling off, easy to install;
4.High-brightness SMD LED (luminous flux maintenance factor of 95%), long life, high CRI, pure color;
5.Choose stable performance constant current source (fast start, no flicker, no noise);
6.IP66 Waterproof as request;
7.Does not contain environmentally harmful mercury pollution, green; Energy saving (power consumption is 80% compared with traditional Spotlights);
8.Long Lifespan (up to 100,000 hours);

Product Specification:

A. General data
Name	Slim LED Flood Light 150W
Model	FG150W12
Input Voltage	100-277VAC
Frequency	50/60 Hz
Power Consumption	150W
Power Factor	>0.95
Beam Angle	30°/60°/90°/120°/T2/T3/T4
IP Rating	IP66
Operating Temperature	-25°C~+45°C
Storage Temperature	-25°C~+65°C
Relative Humidity	10%-90%
LED Lifetime	> 100,000 hrs @ LM70,LM80
Safety Standards	CE&Rohs

Model	FG150W12
Input Voltage	100-277VAC
Frequency	50/60 Hz
Power Consumption	150W
Power Factor	>0.95
Beam Angle	30°/60°/90°/120°/T2/T3/T4
IP Rating	IP66
Operating Temperature	-25°C~+45°C
Storage Temperature	-25°C~+65°C
Relative Humidity	10%-90%
LED Lifetime	> 100,000 hrs @ LM70,LM80
Safety Standards	CE&Rohs

B. Light Data
Model	FG150W12
Light Source	Luminous/Osram 2835 Led Chips
LED QTY	288PCS
Colour Temperature	2700-7000K
Luminous Flux	25500 lm
Luminous Efficiency	170 lm/W(standard) or 190 lm/W(as request)
Colour Rendering Index	>80Ra

C. Packing Data
Model	FG150W12
Product Dimension	30036053 mm
Pcs/CTN	1
Package Dimensions	39033075mm
Net weight/pcs	2.8KG
Gross weight/pcs	3.1KG

Be sure disconnect power before installing, don’t construction with electricity.
Product working voltage is AC100~277V,50/60Hz，Please do not exceed the working voltage range.
Input product line, brown is “L”, blue is “N” , yellow-green is GND.
Be sure wiring is closed and prevent leakage, when installing.
The lamp can not be used in violation of any fire regulations.

Installation and schematic:

200w-slim-led-flood-light-install

150W Outdoor LED flood light is widely used in the single building, the historical building exterior lighting, also waterproof Led flood light used in the building inside the light through the lighting, indoor local lighting, green landscape lighting, billboard lighting, medical culture and other facilities lighting, bars, dance halls and other entertainment Lighting and so on.

slim-led-flood-light-applications
