Modular LED Flood Light

You are here: Home > LED Flood Light > Modular LED Flood Light

Description Product Dimension User Manual Application Cases

Product Features:

Name: 50W Modular Led Flood Light
Brand: Fanguang Lighting
SKU: FG50W18
Availability: InStock
Rating: 5 (1 reviews)

1. Design for widely used as led flood light and led tunnel light;
2. Corrosion resistance.With Anodic oxidation process.Suitable for harsh outdoor enviroment;
3. 1070 Pure aluminum shell,Good Heat Dissipation;
4. Variety of lens design,can meet different reuquest depend on application;
5. Protection rate:IP65;
6. High quality LEDs and drivers are used;
7. Does not contain environmentally harmful mercury pollution, green;Energy saving;
8. Long Lifespan (up to 80,000 hours);

Product Specification:

A.General data

Product Name	LED Flood Light 50W
Model	FG50W18
Input Voltage	100-277VAC
Frequency	50/60 Hz
Power Consumption	50W
Power Factor	>0.95
Optical design	15°/30°/60°/90°/80°*140°/P45
IP Rating	IP65
Operating Temperature	-25°C~+45°C
Storage Temperature	-25°C~+65°C
Relative Humidity	10%-90%
LED Lifetime	> 80,000 hrs @ LM70,LM80
Safety Standards	CE&Rohs

B. Light Data

Model	FG50W18
Light Source	LUMILEDS 3030 Chips
LED QTY	72/108PCS
Colour Temperature	2700~6000K
Luminous Flux	9000lm
Luminous Efficiency	160lm/w or 180lm/w
Colour Rendering Index	>80Ra

C. Packing Data

Model	FG50W18
Product Dimension	34915356mm
Pcs/CTN	1
Package Dimensions	275350150mm
Net weight	2.2KG
Gross weight	2.5KG

Be sure disconnect power before installing, don’t construction with electricity.
Product working voltage is AC100~277V,50/60Hz，Please do not exceed the working voltage range.
Input product line, brown is “L”, blue is “N” , yellow-green is GND.
Be sure wiring is closed and prevent leakage, when installing.
The lamp can not be used in violation of any fire regulations.

50w-led-tunnel-light-fixtures-wire-drawing

Installation and schematic:

50w-led-tunnel-light-fixtures-install

High Grade Led Flood light is widely used in the single building, the historical building exterior lighting, the building inside the light through the lighting, indoor local lighting, green landscape lighting, billboard lighting, medical culture and other facilities lighting, bars, dance halls and other entertainment Lighting and so on.

50w-led-tunnel-light-applications
