Product Features:
1. Taking brander led drivers,with over-temperature protection,high PF,SPD and 0/1-10V,Dali-2.0 Dimming;
2. ADC12 die-casting molding,high thermal conductivity,low temperature,low light decay ;
3. Taking PC optical lens,anti-UV,IK10 grade,above 94% light transmittance;
4. With a waterproof protection grade reaching IP66;
5. It can withstand a level 17 hurricane;
6. Lumileds 2835 as lights source, over 150lm/w output and 80~90Ra;
7. Long Lifespan (up to 100,000 hours);
Product Specification:
A.General data
| Product Name |
Slim LED Street Light 50W |
| Model |
LD50W12 |
| Input Voltage |
100-277VAC |
| Frequency |
50/60 Hz |
| Power Consumption |
50W |
| Power Factor |
>0.95 |
| Optical design |
70°*140° |
| IP Rating |
IP66 |
| Operating Temperature |
-25°C~+45°C |
| Storage Temperature |
-25°C~+65°C |
| Relative Humidity |
10%-90% |
| LED Lifetime |
> 100,000 hrs @ LM70,LM80 |
| Safety Standards |
CE&Rohs |
B. Light Data
| Model |
LD50W12 |
| Light Source |
LUMILEDS 2835 Chips |
| LED QTY |
96PCS |
| Colour Temperature |
2700~7000K |
| Luminous Flux |
7500lm |
| Luminous Efficiency |
150lm/w |
| Colour Rendering Index |
>80Ra |
C. Packing Data
| Model |
LD50W12 |
| Product Dimension |
477*138*96mm |
| Pcs/CTN |
1 |
| Package Dimensions |
415*190*145mm |
| Net weight |
1.5KG |
| Gross weight |
1.85KG |
