Product Features:
1. High efficiency & energy saving.Under the condition of the same llumination,it saves more than 80%
energy compared with the traditional lamp;
2. High performance external constant current drivers,no stroboscopic,good for eyesight protection;
3. Eco-friendly,No Hg & Xe ,or other harmful element.Recyclable,also it won’t generate EMI;
4. No UV & IR.It won’t distribute ray radiation;
5. Does not contain environmentally harmful mercury pollution,green,Energy saving;
6. Long life span,using semiconductor chip as the light resource,the life can be over 100,000hrs;
Product Specification:
A.General data
| Product Name |
CCT Led Panel Light |
| Model |
PL6060-40W |
| Input Voltage |
100-277VAC |
| Frequency |
50/60 Hz |
| Power Consumption |
40W |
| Power Factor |
>0.9 |
| Optical design |
120° |
| IP Rating |
IP44/IP65 |
| Operating Temperature |
-25°C~+45°C |
| Storage Temperature |
-25°C~+65°C |
| Relative Humidity |
10%-90% |
| LED Lifetime |
> 100,000 hrs @ LM70,LM80 |
| Safety Standards |
CE&Rohs |
B. Light Data
| Model |
PL6060-40W |
| Light Source |
Luminus 2835 Chips |
| LED QTY |
64PCS |
| Colour Temperature |
2700~6000K |
| Luminous Flux |
4000lm or Customized |
| Luminous Efficiency |
100lm/w,120lm/w,150lm/w,180lm/w |
| Colour Rendering Index |
>80Ra(90Ra) |
C. Packing Data
| Model |
PL6060-40W |
| Product Dimension |
595*595*30mm |
| Pcs/CTN |
5 |
| Package Dimensions |
660*365*675mm |
| Net weight |
9.75KG |
| Gross weight |
13.1KG |
